CONSTRUCTION ARCHIVE
Facility Photos
Completed in March 2023.
View past construction schedules and status reports here.
Main Building Construction
Topping-out Ceremony
Held on May 19, 2021.
The ceremony celebrated the completion of the building's structural frame and prayed for the safe completion of the remaining work.
Column Setting Ceremony
Held on January 26, 2021.
Marked the installation of the first steel column of the main building, praying for safety during the assembly process.
Groundbreaking Ceremony
Construction of the main building began on March 27, 2020.
On April 22, the groundbreaking ceremony was held with maximum consideration for preventing the spread of the novel coronavirus, such as strictly limiting the number of attendees and ensuring sufficient space between them.
Land Development
Safety Prayer Ceremony
March 2019: Commenced land preparation.
Development work began at the Tohoku University Aobayama New Campus after obtaining all necessary permits.
Completion of Land Development
The land development work passed all inspections and was completed on November 30, 2020.
Before Construction (Mar 2019)
Phase 1 Completion (Mar 2020)
Phase 2 Completion (Nov 2020)
Project Overview
Period: Jan 25, 2019 – Nov 30, 2020
Contractor: Hashimoto-ten Co., Ltd.
Design/Supervision: Asia Air Survey Co., Ltd.
| Site Development |
Development Area: 60,795m2 (Cut: 49,320m2, Fill: 11,475m2) Earthwork Volume: 156,045m3 (Excavation: 141,630m3, Fill: 14,415m3) Deforestation: 400 trees |
|---|---|
| Removal of Internal Roads, etc. |
Internal Road 7: Removed Asphalt Pavement (t=5cm): Length 416.4m, Width 6.0m Removal of L-shaped gutters, street catch basins, car stops, eco-tunnels |
| Relocation of Internal Roads |
Relocation of Internal Road 7 Asphalt Pavement (t=5cm): Length 448m, Width 6.0m Installation of L-shaped gutters, street catch basins, boundary blocks |
| Construction of Management Roads |
Crushed Stone Pavement (t=20cm): Width 4.0–6.0m Length: 435.24m |
| Removal of Drainage Systems | Rainwater drainage pipes L=318.6m, Sewage pipes L=359.7m, Removal of 20 manholes, etc. |
| Restoration of Drainage Systems | Rainwater drainage pipes L=295.3m, Installation of 16 manholes, 6 connecting pipes, etc. |
| Electrical Systems | High-voltage cables, streetlights, power cables, security poles, etc. |
| Water Supply Systems | Water supply pipes L=370.0m, Valve installation |
| Landscaping | Turf placement: 5,413m2 |
